DEWALT DCS334B 20V MAX XR brushless jig saw cuts up to 3,200 SPM with 4-position orbital action and an LED light—tool only, powered by all DEWALT 20V MAX batteries.
Categories : tools
SKU : WOR-TOO-034
Share This:
The DEWALT DCS334B 20V MAX XR Brushless Jig Saw is a professional-grade cordless jig saw designed for precise, efficient cutting in wood, metal, and plastic. With variable speed up to 3,200 SPM and a 4-position orbital action, it adapts to your material and cut quality. The all-metal, lever-action keyless blade clamp allows quick T-shank blade changes, while the integrated LED light keeps your work area visible.
Because the DCS334B is a bare tool, it draws power from the entire DEWALT 20V MAX battery platform. From compact 1.5Ah packs to high-capacity 6.0Ah XR batteries, it runs on all of them. For longer cutting sessions or thick hardwood, choose a higher-capacity pack such as the DCB205 or DCB206. All DEWALT 20V MAX chargers are compatible.
Selecting the right T-shank blade makes a significant difference in cut quality. For clean wood cuts, use a high-carbon steel blade with 6-8 TPI. For metal, a bi-metal blade with 14-24 TPI is ideal. The DCS334B's all-metal keyless clamp works with standard T-shank blades, so you have a wide range of options from brands like DEWALT, Bosch, and Milwaukee.
The 4-position orbital action lets you adjust how aggressively the blade moves forward and backward. Position 0 is a straight cut for wood and metal, while positions 1-3 increase orbital action for faster cuts in softwood or thicker material. The variable speed trigger and dial give you fine control from 0 to 3,200 SPM, so you can slow down for intricate curves or speed through long cuts.
This bare tool includes the DCS334B jig saw, a T-shank blade, anti-splinter shoe, and hex wrench. Keep the air vents clear of sawdust, wipe the shoe after use, and store it in a dry case. The all-metal lever clamp is designed for quick blade changes on the job site.
Brushless motor delivers longer runtime and more power than brushed models (vs DCS331).
4-position orbital action controls cut speed and finish for wood, metal, and plastic.
All-metal keyless lever clamp swaps T-shank blades in seconds.
Variable speed trigger and dial give precise control from 0 to 3,200 SPM.
Integrated dust blower and LED keep cut lines visible.
Model: DCS334B
Weight: 5.5 lb (2.5 kg)
Blade Type: T-shank
Dimensions: 10.8 x 4.3 x 8.0 in (27.4 x 10.9 x 20.3 cm)
Power Source: 20V MAX Battery (tool only)
Product Type: Cordless Jig Saw
Bevel Capacity: 0°, 15°, 30°, 45° with detents and positive stop
Orbital Action: 4-position
Max Blade Speed: 3,200 SPM
Package Contents: DCS334B jig saw, T-shank blade, anti-splinter shoe, hex wrench
Seller: Workbench World
MPN: DCS334B
Position 0 gives a straight up-and-down motion for clean cuts in hardwoods and metals. Position 1 provides a slight orbital action for smoother, faster cuts in softwood. Positions 2 and 3 add more aggressive orbital action, ideal for rough cutting in thick lumber or plastic. Experiment to find the best setting for your project.
A 4Ah XR battery is a good starting point, providing about 30 minutes of mixed cutting. For extended production work, a 6Ah pack nearly doubles that runtime. Since the DCS334B is brushless, you'll get more efficient use of every charge than with a brushed jig saw.
Use a fine-tooth blade for smooth cuts in plywood, a medium-tooth blade for general wood, and a bi-metal blade for metal. For curves, choose a narrow blade to turn easily. The lever-action clamp lets you switch blades in under five seconds, so you can adapt to the job quickly.
The DCS334B is compatible with all DEWALT 20V MAX batteries, from compact 1.5Ah to XR 6.0Ah packs. It will also work with FLEXVOLT batteries when in 20V mode.
For wood, use a T-shank blade with 6–8 TPI. For metal, choose a bi-metal blade with 14–24 TPI. The tool-free clamp works with any standard T-shank blade.
There's a small lever near the blade clamp. Move it between 0 (straight cut) and 3 (aggressive orbital) to match the material and cut speed.
Yes, the integrated LED illuminates the cut line.
Yes, the shoe tilts up to 45° with detents at 0°, 15°, 30°, and a positive stop at 45°.
Very precise.
The orbital settings help. It's a bit heavy. But it cuts clean.
I make furniture and this jigsaw is excellent. The variable speed lets me control the cut. The orbital action helps with harder woods. The LED lights the line. The blade changes are easy. The anti-splinter insert works. It's my favorite jigsaw now.
Blade wobbles.
I'm a carpenter. This jigsaw is my sidekick. It cuts through 2x4s like butter. The dust blower keeps the line visible. The tool-free blade change is great. The battery lasts long. I recommend it.
It's accurate. The LED is helpful. The orbital function is a plus.
Cuts tight circles.
The variable speed is useful. It's quiet. The case is good. Wish it came with more blades.
I'm a DIYer and this jigsaw is perfect for my crafts. It's easy to maneuver. The cuts are smooth. The LED helps a lot. The battery lasts a good while. I'm very happy.
Works well.
